Steer and Observe LLMs with NVIDIA NeMo Guardrails and Fiddler

The future of Generative AI (GenAI) is bright as it continues to help enterprises enhance their competitive advantage, boost operational efficiency, and reduce costs. With AI Observability, enterprises can ensure deployed large language model (LLM) applications are monitored for correctness, safety, and privacy, among other LLM metrics.

NVIDIA’s NeMo Guardrails + Fiddler AI Observability for accurate, safe, and secure LLM applications

Together, NVIDIA’s NeMo Guardrails and the Fiddler AI Observability Platform provide a comprehensive solution for enterprises to gain the most value from their highly accurate and safe LLM deployments while derisking adverse outcomes from unintended LLM responses.

NeMo Guardrails is an open-source toolkit designed to  add programmable guardrails to LLM applications, allowing developers and engineers to control and mitigate risks in real-time conversations. The Fiddler AI Observability Platform provides rich insights into prompts and responses, enabling the improvement of LLMOps. It complements NeMo Guardrails and helps to:

• monitor key LLM metrics, including hallucinations (faithfulness, answer relevance, coherence)
• safety (PII, toxicity, jailbreak)
• operational metrics (cost, latency, data quality)

In this blog, we provide details on how application engineers and developers can deploy LLM applications with NeMo Guardrails and monitor NeMo Guardrails’ metrics as well as LLM metrics in the Fiddler AI Observability Platform.

How the NeMo Guardrails and Fiddler Integration Works

NeMo Guardrails provides a rich set of rails to moderate and safeguard conversations. Developers can choose to define the behavior of the LLM-based application on specific topics and prevent it from engaging in discussions on unwanted topics. Additionally, developers can steer the LLM to follow pre-defined conversational paths to ensure reliable and trustworthy dialog [1].

Application code interacts with LLMs through NeMo Guardrails and pushes logs to Fiddler for LLM observability

Once integrated, the prompts, responses, metadata, and the rails executed in NeMo Guardrails for each conversation can be published to Fiddler. This enables developers to observe and gain insights into the rails executed in a conversation from NeMo Guardrails. Developers can also define a rich set of alerts on the rails information published to Fiddler. In addition to rails information, the Fiddler AI Observability Platform also provides a wide variety of metrics to detect hallucination, drift, safety, and operational issues. Developers obtain rich insights into their rails and LLM metrics using Fiddler custom dashboards and reports, enabling them to perform deep root cause analysis to pinpoint and address issues.

Visualize rails executed by NeMo Guardrails in the Fiddler AI Observability Platform

Set up NeMo Guardrails Fiddler Integration

This section dives into details on how to publish logs from NVIDIA NeMo Guardrails to the Fiddler platform.

Prerequisites

• Access to the LLM provider key
• Access to the Fiddler deployment
• Python environment for running the application code

You can begin by setting up your Python environment. Ensure you have the following packages installed from PyPI:

pandas fiddler-client nemoguardrails nest-asyncio

pandas fiddler-client nemoguardrails nest-asyncio

Integration Code Walk-through

Then once installed, go ahead and import the packages.

import os import logging import pandas as pd import fiddler as fdl import nest_asyncio from nemoguardrails import LLMRails, RailsConfig

import os import logging import pandas as pd import fiddler as fdl import nest_asyncio from nemoguardrails import LLMRails, RailsConfig

You’ll also want to set the OpenAI API key as an environment variable.

os.environ['OPENAI_API_KEY'] = '' # Add your OpenAI API key here

Great, you’re done getting set up.

Below is a snippet for the NeMo Guardrails Fiddler integration code. Just define the FiddlerLogger class in your environment and you can start sending your rails output to the Fiddler AI Observability Platform.

class FiddlerLogger:  def __init__(self, project_name, model_name, decisions):  self.project_name = project_name  self.model_name = model_name  self.decisions = decisions  self.project = None  self.model = None

class FiddlerLogger:  def __init__(self, project_name, model_name, decisions):  self.project_name = project_name  self.model_name = model_name  self.decisions = decisions  self.project = None  self.model = None

try: self.project = fdl.Project.from_name(self.project_name) except: pass

try: self.model = fdl.Model.from_name( project_id=self.project.id, name=self.model_name ) except: pass

self.logger = self.configure_logger()

def configure_logger(self):

logger = logging.getLogger(name) logger.setLevel(logging.INFO)

class FiddlerHandler(logging.Handler): def init(self, level, project, model, decisions, preprocess_function): super().init(level=level) self.project = project self.model = model self.decisions = decisions self.preprocess_function = preprocess_function

def emit(self, record): log_entry = self.preprocess_function(record.dict['payload']) self.send_to_fiddler(log_entry)

def send_to_fiddler(self, log_entry): self.model.publish([log_entry])

handler = FiddlerHandler( level=logging.INFO, project=self.project, model=self.model, decisions=self.decisions, preprocess_function=self.preprocess_for_fiddler )

for hdlr in logger.handlers: logger.removeHandler(hdlr)

logger.addHandler(handler)

return logger

def preprocess_for_fiddler(self, record): last_user_message = record.output_data["last_user_message"] last_bot_message = record.output_data["last_bot_message"]

log_entry = { "last_user_message": last_user_message, "last_bot_message": last_bot_message }

for rail in record.log.activated_rails: sanitized_rail_name = rail.name.replace(" ", "") for decision in self.decisions: sanitized_decision_name = decision.replace(" ", "") log_entry[sanitized_rail_name + "" + sanitized_decision_name] = 1 if decision in rail.decisions else 0

return log_entry

def generate_fiddler_model(self, rail_names):

project = fdl.Project(name=self.project_name) project.create()

self.project = project

rail_column_names = []

for rail_name in rail_names: sanitized_rail_name = rail_name.replace(" ", "") for decision in self.decisions: sanitized_decision_name = decision.replace(" ", "") rail_column_names.append(sanitized_rail_name + "" + sanitized_decision_name)

schema = fdl.ModelSchema( columns=[ fdl.schemas.model_schema.Column(name='last_user_message', data_type=fdl.DataType.STRING), fdl.schemas.model_schema.Column(name='last_bot_message', data_type=fdl.DataType.STRING) ] + [ fdl.schemas.model_schema.Column(name=rail_column_name, data_type=fdl.DataType.INTEGER, min=0, max=1) for rail_column_name in rail_column_names ] )

spec = fdl.ModelSpec( inputs=['last_user_message'], outputs=['last_bot_message'], metadata=rail_column_names )

task = fdl.ModelTask.LLM

model = fdl.Model( name=self.model_name, project_id=project.id, schema=schema, spec=spec, task=task )

model.create()

self.model = model

self.logger = self.configure_logger()

def log_to_fiddler(self, record): self.logger.info("Logging event to Fiddler", extra={'payload': record})`

Now you’re ready to initialize the logger. Set up your rails object and make sure to create an options dictionary as shown below to ensure Guardrails produces the necessary logs for you to send to Fiddler.

config_path = "/path/to/config/dir/"

config = RailsConfig.from_path(config_path) rails = LLMRails(config)

options = { "output_vars": True, "log": { "activated_rails": True }, }`

Now you can connect to Fiddler. Obtain a Fiddler URL and API token from your Fiddler administrator and run the code below.

fdl.init(  url='', # Add your Fiddler URL here  token='' # Add your Fiddler API token here )

fdl.init(  url='', # Add your Fiddler URL here  token='' # Add your Fiddler API token here )

You’re ready to create a FiddlerLogger object. Here, you’ll define the project and model on the Fiddler platform to which you want to send data.

Additionally, you’ll specify a list of decisions, which are the actions within your rails that you’re interested in tracking. Any time one of these decisions gets activated in a rail, it will get flagged within Fiddler.

logger = FiddlerLogger(  project_name='rails_project',  model_name='rails_model',  decisions=[  'execute generate_user_intent',  'execute generate_next_step',  'execute retrieve_relevant_chunks',  'execute generate_bot_message'  ] )

logger = FiddlerLogger(  project_name='rails_project',  model_name='rails_model',  decisions=[  'execute generate_user_intent',  'execute generate_next_step',  'execute retrieve_relevant_chunks',  'execute generate_bot_message'  ] )

Optionally, you can generate a Fiddler model using the FiddlerLogger class. If you’d rather go ahead and create your own model, feel free. But if you’re looking to get started with a jumping-off point, run the code below.

Here, rail_names is the list of rails you’re interested in tracking decisions for.

logger.generate_fiddler_model(  rail_names=[  'dummy_input_rail',  'generate_user_intent',  'generate_next_step',  'generate_bot_message',  'dummy_output_rail'  ], )

logger.generate_fiddler_model(  rail_names=[  'dummy_input_rail',  'generate_user_intent',  'generate_next_step',  'generate_bot_message',  'dummy_output_rail'  ], )

You’re now ready to start sending data to Fiddler. Run rails.generate and make sure to pass in both the prompt (in messages) and the options dictionary you created earlier.

Then just pass the output of that call into the logger’s log_to_fiddler method.

nest_asyncio.apply()

messages=[{ "role": "user", "content": "What can you do for me?" }]

output = rails.generate( messages=messages, options=options )

logger.log_to_fiddler(output)`

That’s it! Your Guardrails output will now be captured by Fiddler.

Summary

Enterprises can fully leverage the benefits of GenAI by addressing risks in LLMs, and operationalizing accurate, safe, and secure LLM applications. By integrating NVIDIA NeMo Guardrails with the Fiddler AI Observability Platform, application engineers and developers are now equipped to guide real-time conversations, as well as monitor and analyze data flowing from NeMo Guardrails into Fiddler. This integration ensures comprehensive oversight and enhanced control over their LLM applications.

Experience Fiddler LLM Observability in action with a guided product tour.

—

References

[1] https://docs.nvidia.com/nemo/guardrails/introduction.html#overview
